Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 323
11 Appendix
11.1 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x3307 VFC: Load adjustment - parameter
1: VFC: Load adjustment - direction of rotation UNSIGNED_8 - P CINH
2: VFC: Load adjustment - value UNSIGNED_32 1/100 P
0x3308
VFC: Imax controller - parameter
1: VFC: Imax controller - gain UNSIGNED_32 1/1000 P
2: VFC: Imax controller - reset time UNSIGNED_32 1/10 P
0x3309
VFC: Slip compensation - parameter
1: VFC: Slip compensation - influence INTEGER_16 1/100 P
2: VFC: Slip compensation - filter time UNSIGNED_16 - P
0x330A
VFC: Oscillation damping - parameter
1: VFC: Oscillation damping - gain INTEGER_16 - P
2: VFC: Oscillation damping - filter time UNSIGNED_16 - P
3: VFC: Oscillation damping - limitation UNSIGNED_16 1/10 P
4: VFC: Oscillation damping - final ramp
frequency
UNSIGNED_8 - P
0x330B
VFC: Frequency setpoint INTEGER_16 1/10 OSC Tx
0x330C VFC: Override point of field weakening INTEGER_16 1/10 P
0x3380
DC-injection braking: Current UNSIGNED_16 1/100 P
0x33A0
Flying restart: Activate UNSIGNED_8 - P
0x33A1
Flying restart: Current UNSIGNED_16 - P
0x33A2
Flying restart: Start frequency INTEGER_16 1/10 P
0x33A3
Flying restart: Integration time UNSIGNED_16 - P
0x33A4
Flying restart: Min. deviation UNSIGNED_16 1/100 P
0x33A5
Flying restart: Delay time UNSIGNED_16 - P
0x33A6
Flying restart: Result
1: Flying restart: Determined speed [rpm] INTEGER_16 - OSC Tx
2: Flying restart: Determined speed [n unit] INTEGER_32 480000/
2
31
OSC Tx
Axis B - motor settings
0x3400
Motor control UNSIGNED_8 - P CINH
0x3401
Motor: Common parameters
1: Motor: Number of pole pairs UNSIGNED_8 -
2: Motor: Stator resistance UNSIGNED_32 1/10000 P
3: Motor: Stator leakage inductance UNSIGNED_32 1/1000 P
4: Motor: Rated speed UNSIGNED_16 - P
5: Motor: Rated frequency UNSIGNED_16 1/10 P
6: Motor: Rated power UNSIGNED_16 1/100 P
7: Motor: Rated voltage UNSIGNED_16 - P
8: Motor: Rated cosine phi UNSIGNED_16 1/100 P
9: Motor: Insulation class UNSIGNED_8 - P
10: Motor: Designation STRING(50) - P
0x3402
Motor (ASM): Parameter
1: Motor (ASM): Rotor resistance UNSIGNED_32 1/10000 P
2: Motor (ASM): Mutual inductance UNSIGNED_32 1/10 P
3: Motor (ASM): Magnetising current UNSIGNED_16 1/100 P
0x3403
Motor (SM): Parameter
1: Motor (SM): e.m.f. constant (KELL) UNSIGNED_32 1/10 P
2: Motor (SM): Pole position INTEGER_16 1/10 P
3: Motor (SM): Temperature coefficient -
magnets (kTN)
INTEGER_16 1/1000 P
4: Motor (SM): Pole position INTEGER_16 1/10 P
Index Name Data type Factor Attributes
Greyed out = read only
