3 Communication with the controller
3.6 Ethernet over EtherCAT (EoE)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Read parameters
The service identification (GSV) = 0x82 in the GCI header serves to read parameter data from the
i700 servo inverter:
Write parameters
The service identification (GSV) = 0x83 in the GCI header serves to write parameter data to the i700
servo inverter:
Client
(PC)
Server
(i700)
Request
Request
 GMT GSV GMQ GTI SIZE SIZE res res
User data

Indication
0x01 0x82 0x00 0xXX 0xXX 0xXX 0x00 0x00
Answer
Confirmation
 GMT GSV GMQ GTI SIZE SIZE res res
User data
(error code)

Response
0x01 0x82 0x80 0xXX 0xXX 0xXX 0x00 0x00
Client
(PC)
Server
(i700)
Request
Request
 GMT GSV GMQ GTI SIZE SIZE res res
User data

Indication
0x01 0x83 0x00 0xXX 0xXX 0xXX 0x00 0x00
Answer
Confirmation
 GMT GSV GMQ GTI SIZE SIZE res res
User data
(error code)

Response
0x01 0x83 0x80 0xXX 0xXX 0xXX 0x00 0x00

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
