4 Device settings
4.5 Monitoring of the DC-bus voltage
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Related topics:
24-V supply voltage monitoring
( 251)
0 V 800 800 V
Write access CINH OSC P RX TX UNSIGNED_16
Subindex 7: Overvoltage (OU): Threshold 'Reset error'
Display of the error reset threshold for monitoring with regard to overvoltage
Display area (min. value | unit | max. value) Initialisation
0 V 800 790 V
Write access CINH OSC P RX TX UNSIGNED_16
Subindex 8: Critical DC-bus voltage
Display area (min. value | unit | max. value) Initialisation
0 1
Write access CINH OSC P RX TX UNSIGNED_8
Subindex 6: Overvoltage (OU): Error threshold
