Lenze i700

Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 56
5 Motor control & motor settings
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2B05 0x3305 VFC: Voltage vector control parameter RECORD
0x2B06
0x3306 VFC: Voltage boost UNSIGNED_16
0x2B07
0x3307 VFC: Load adjustment - parameter RECORD
0x2B08
0x3308 VFC: Imax controller - parameter RECORD
0x2B09
0x3309 VFC: Slip compensation - parameter RECORD
0x2B0A
0x330A VFC: Oscillation damping - parameter RECORD
0x2B0B
0x330B VFC: Frequency setpoint INTEGER_16
0x2B0C
0x330C VFC: Override point of field weakening INTEGER_16
0x2B80
0x3380 DC-injection braking: Current UNSIGNED_16
0x2BA0
0x33A0 Flying restart: Activate UNSIGNED_8
0x2BA1
0x33A1 Flying restart: Current UNSIGNED_16
0x2BA2
0x33A2 Flying restart: Start frequency INTEGER_16
0x2BA3
0x33A3 Flying restart: Integration time UNSIGNED_16
0x2BA4
0x33A4 Flying restart: Min. deviation UNSIGNED_16
0x2BA5
0x33A5 Flying restart: Delay time UNSIGNED_16
0x2BA6
0x33A6 Flying restart: Result RECORD
Motor settings
0x2C00
0x3400 Motor control UNSIGNED_8
0x2C01
0x3401 Motor: Common parameters RECORD
0x2C02
0x3402 Motor (ASM): Parameter RECORD
0x2C03
0x3403 Motor (SM): Parameter RECORD
0x2C04
0x3404 Motor: Lss saturation characteristic - inductance grid points (y) RECORD
0x2C05
0x3405 Motor: Lss saturation charcteristic - reference for current grid points (x) UNSIGNED_16
0x2C06
0x3406 Motor (SM): Magnet characteristic (current) - grid points RECORD
0x2C07
0x3407 Motor (ASM): Lh saturation characteristic - inductance grid points (y) RECORD
0x2C08
0x3408 Motor: Motor parameter setting method UNSIGNED_8
0x6075 0x6875 Motor rated current UNSIGNED_32
0x6076
0x6876 Motor rated torque UNSIGNED_32
Feedback system
0x2C40 0x3440 Encoder: Type UNSIGNED_8
0x2C41
0x3441 Hiperface: Parameter RECORD
0x2C42
0x3442 Encoder: Parameter RECORD
0x2C43
0x3443 Resolver: Number of pole pairs UNSIGNED_8
0x2C44
0x3444 Resolver error compensation: Parameter RECORD
0x2C45
0x3445 Open circuit in feedback system: Response UNSIGNED_8
0x2C46
0x3446 Feedback system: Specifiable number of revolutions UNSIGNED_16
0x2C5F
0x345F Feedback system: Parameter CRC UNSIGNED_32
Pole position identification
0x2C60
0x3460 Monitoring pole position identification: Response UNSIGNED_8
0x2C61
0x3461 Pole position identification PPI (360°) RECORD
0x2C62
0x3462 Pole position identification PPI (min. movement) RECORD
0x2C63
0x3463 Pole position identification PPI (without movement) RECORD
Advanced settings
0x2DE0
0x35E0 Advanced settings RECORD
Object Name Data type
Axis A Axis B
