8400 BaseLine D | Software Manual
Motor control (MCTRL)
Selection of the operating mode
88 L Firmware 03.00 - DMS EN 5.0 - 07/2009
Selection and parameter setting of the motor
A. Select the motor from the »Engineer« motor catalogue.
Continue with step [C]
.
• If the Lenze motor is not listed there, continue with step [B]
.
• If you use an external motor, continue with [B]
and
•then [C]
or [D]
B. Prepare the motor parameter identification by setting the following data taken from
the motor nameplate:
• Rated motor power C081
• Rated motor speed C087
• Rated motor current C088
• Rated motor frequency C089
• Rated motor voltage C090
•Motor cos ϕ C091
C. Carry out motor parameter identification C002/23
The following parameters are identified and automatically transmitted to the
corresponding codes:
• Motor leakage inductance C085
• Mutual motor inductance C092
• Stator resistance (total resistance from motor cable resistance and stator
resistance) C084
D. Enter the nameplate data and the equivalent circuit data of the external motor:
• Rated motor power C081
• Rated motor speed C087
• Rated motor current C088
• Rated motor frequency C089
• Rated motor voltage C090
•Motor cos ϕ C091
• Stator resistance C084
• Stator inductance C092
• Leakage inductance C085
The field-oriented sensorless vector control is now ready for operation.
