Technical data
Leuze electronic RSL 430 121
Byte Bit Signal Description Value "0" Value "1" Default
Protective function A
12 7 A-ACTIVE Protective function A is active /
configured
off Active 0
6 A-WF-VIO Status of active warning field
Protective function A
violation free 0
5 A-PF-VIO Status of active protective field
Protective function A
violation free 0
4 A-RES Start/restart interlock active
Start RequestA
off Active 0
3 A-CLEAR Internal signal OSSDA off on 0
2 Reserved --- --- --- ---
1 Reserved --- --- --- ---
0 Reserved --- --- --- ---
Field pair selectionA
13 7-4 A-BANK-SEL Selected bankA
Numbers 1…10
--- --- 0
3-0 A-PAIR-SEL1 First selected field pairA
Numbers 1…10
--- --- 0
14 7-4 A-PAIR-SEL2 Second selected field pairA
Numbers 1…10
--- --- 0
3-0 A-PAIR-SEL3 Third selected field pairA
Numbers 1…10
--- --- 0
Output signalsA
15 7 A-WF-VIO-SEG-1 Status of active warning field seg-
ment
Protective function A
violation free 0
6 A-WF-VIO-SEG-2 Status of active warning field seg-
ment
Protective function A
violation free 0
5 A-PF-VIO-SEG-1 Status of active protective field
segment
Protective function A
violation free 0
4 A-PF-VIO-SEG-2 Status of active protective field
segment
Protective function A
violation free 0
3 A-FP-SEL-1 Defined field pair selected
Protective function A
off selected 0
2 A-FP-SEL-2 Defined field pair selected
Protective function A
off selected 0
1 Reserved --- --- --- ---
0 Reserved --- --- --- ---
