Technical data
Leuze electronic RSL 430 122
Byte Bit Signal Description Value "0" Value "1" Default
Protective function B
16 7 B-ACTIVE Protective function B is active /
configured
off Active 0
6 B-WF-VIO Status of active warning field
Protective function B
violation free 0
5 B-PF-VIO Status of active protective field
Protective function B
violation free 0
4 B-RES Start/restart interlock active
Start requestB
off Active 0
3 B-CLEAR Internal signal OSSDB off on 0
2 Reserved --- --- --- ---
1 Reserved --- --- --- ---
0 Reserved --- --- --- ---
Field pair selectionB
17 7-4 B-BANK-SEL Selected bankB
Numbers 1…10
--- --- 0
3-0 B-PAIR-SEL1 First selected field pairB
Numbers 1…10
--- --- 0
18 7-4 B-PAIR-SEL2 Second selected field pairB
Numbers 1…10
--- --- 0
3-0 B-PAIR-SEL3 Third selected field pairB
Numbers 1…10
--- --- 0
Output signalsB
19 7 B-WF-VIO-SEG-1 Status of active warning field seg-
ment
Protective function B
violation free 0
6 B-WF-VIO-SEG-2 Status of active warning field seg-
ment
Protective function B
violation free 0
5 B-PF-VIO-SEG-1 Status of active protective field
segment
Protective function B
violation free 0
4 B-PF-VIO-SEG-2 Status of active protective field
segment
Protective function B
violation free 0
3 B-FP-SEL-1 Defined field pair selected
Protective function B
off selected 0
2 B-FP-SEL-2 Defined field pair selected
Protective function B
off selected 0
1 Reserved --- --- --- ---
0 Reserved --- --- --- ---
