USING THE PROGRAM
Channel Setting
The following explains channel setting of ACS IV Controller.
ACP IV, ACP BACnet
Item Description
CH5
y LGAP_AHU: AHU(Normal, Fresh Air, Heat Recovery) connection.
y MODBUS_9600, MODBUS_19200: AHU(Modular Fresh Air,
Modular Heat Recovery, DOAS), Exp.I/O, Chiller connection.
CH6
y DEMAND: Demand Controller connection
y MODBUS_9600, MODBUS_19200: AHU(Modular Fresh Air,
Modular Heat Recovery, DOAS), Exp.I/O, Chiller connection.
NOTES
The default MODBUS communication setting is MODBUS_9600.
