USING THE PROGRAM
ABS chiller
The following menu controls the configuration and function of the ABS chiller.
Item Description
Operation
y [ON] Button: Starts the operation of the device.
y [OFF] Button: Stops the operation of the device.
GoTo
y [Schedule ▶] Button: Move to Schedule menu.
y [View Details ▶] button: Moves to detail information screen.
Mode
(not activated)
y ABS chiller: Cool/Heat
Mode Target
Temp (°C)
Click(Touch) [▲]/[▼] to setting of the Mode set temperature.
y ABS chiller
- Cool: 3 °C ~ 20 °C
- Heat: 40 °C ~ 80 °C
Control Valve
Limit
Function to maintain the cycle by limiting the heat source inlet calories at
chiller operation. Heat input so that it will not be any more to set the maximum
value of the control valve (%).
Click(Touch) [▲]/[▼] to setting the Control valve limit within the range of 0 to
100%.
[Apply] Button Apply control menu setting to the device.
[Detail. ▶] Button
Controls details.
