USING THE PROGRAM
• ABS chiller Fine Control
You can control the details in the detail control window that appears when you touch the [Detail
control ▶] button on the control menu of the ABS chiller . Configuration and functions of the
Advanced menu is as follows.
Item Description
Operation
y [ON] Button: Starts the operation of the device.
y [OFF] Button: Stops the operation of the device.
Mode
(not activated)
y [COOL] Button: Operates with Cooling Mode.
y [HEAT] Button: Operates with Heating Mode.
Control Valve
Limit
Function to maintain the cycle by limiting the heat source inlet
calories at chiller operation. Heat input so that it will not be any more
to set the maximum value of the control valve (%).
Click(Touch) [▲]/[▼] to setting the Control valve limit within the range
of 0 to 100%.
Mode Target
Temp (℃)
Click(Touch) [▲]/[▼] to setting of the Mode set temperature.
y ABS chiller
- Cool: 3 °C ~ 20 °C
- Heat: 40 °C ~ 80 °C
