Liebert Vertiv GXT5 User Manual

Specications108
Table 7-3 UPS Specifications, 3000 VA Models
MODEL GXT5- 3000IRT2UXL* 3000IRT2UXLE
RATING 3000 VA/3000 W
Dimensions, D×W×H, in. (mm)
Unit 21.3 x 16.9 x 3.4 (540 × 430 × 85)
Shipping 28.2 x 22.4 x 10.3 (717 x 570 x 262)
Weight, kg (lb)
Unit
28.2 (62)
Shipping
36 (79.2) 33 (72.6)
Input AC
Voltage Range (typical)
230VAC nominal;
variable based on output load
90% ~ 100% loading 184 to 288 VAC
70% ~ 90% loading 161 to 288 VAC
50%~70% loading 115 to 288 VAC
0%~50% 115 to 288 VAC
Frequency 40 Hz ~ 70 Hz; Auto Sensing
Input Power Cord C20
Output AC
Output Receptacles C13×6&C19
Voltage 200/208/220/230/240 VAC (user-congurable); ±3%
Waveform Sine wave
Utility (AC) Model
Overload
200% for 250 ms; 150 to 200% for 2 seconds; 105% to 125% for 55 seconds;
125% to 150% for 55 seconds
Internal Battery Charger
Charger Current, A default 2.2 A; Maximum 8 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Qty×V×Rating 6 × 12V × 9.0 Ah
Battery Mfr./Part# LEOCH DJW12-9.0
Back-up time See Battery Run Times on page 120.
Recharge Time
3 Hours to 90% capacity after full discharge with 100% load till UPS auto-shutdown (Internal
Batteries Only)
Bypass Parameters
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable-bypass
operation
When the input frequency prevents synchronous operation.

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
