Vertiv | Liebert® GXT5™ | Installer/User Guide 109
MODEL GXT5- 3000IRT2UXL* 3000IRT2UXLE
RATING 3000 VA/3000 W
Environmental Requirements
Operating Temperature,
°F (°C)
+32 to +122 (0 to 50); Operating temperature may be increased to 122 °F (50 °C with a 10%
derating of the output power
Storage Temperature, °F
(°C)
-4 to +140 (-20 to 60)( contain batteries will be from -15 to 40 °C.)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000 m) at 77ºF (25ºC) without derating
Audible Noise <48 dBA max @ 3 ft. (1 m) front and sides <48 dBA max @ 3 ft. (1 m) rear
Agency
Safety
Transportation ISTA Procedure 1A
Surge Immunity ANSI C62.41 Category B
RFI/EMI CISPR22 Class A (RFI)/ FCC Part 15 (Class A)
*Only these models are available in the ASIA PACIFIC region.
Table 7-4 UPS Specifications, 5-kVA and 6-kVA models
MODEL GXT5- 5000IRT5UXLN* 5000IRT5UXLE 6000IRT5UXLN* 6000IRT5UXLE
RATING 5000 VA/5000 W 6000 VA/6000 W
Dimensions, D×W×H, in. (mm)
Unit 430 × 630 × 217 (16.9 × 24.8 × 8.5)
Shipping 600 × 800 × 520 (23.6 × 31.5 × 20.5)
Weight, kg (
lb)
Unit 70.8 (156) 70.8 (156)
Shipping 92 (202.8) 89 (196.2) 92 (202.8) 89 (196.2)
Input AC Parameters
Operating Frequency,
Nom.
50 or 60 Hz (factory-default is 50 Hz)
Factory-default VAC 230 VAC
Operating voltage
range without battery
operation
176 to 288 VAC (100 – 176 VAC with power derating)
Maximum Allowable VAC 288 VAC
Input frequency without
battery
operation
40 to 70 Hz
Input Power Connection PD5-CE6HDWRMBS PD5-CE6HDWRMBS
UL-1778 (Fifth Edition), C-UL listed, IEC 62040-1: 2008 (First Edition) + Am 1:2013, EN 62040-1:2008+A1:2013
