Liebert Vertiv GXT5 User Manual

Specications110
MODEL GXT5- 5000IRT5UXLN* 5000IRT5UXLE 6000IRT5UXLN* 6000IRT5UXLE
RATING 5000 VA/5000 W 6000 VA/6000 W
Output AC Parameters
AC-AC Eiciency 94%
Factory-default VAC
Frequency
230 VAC, 50 Hz
Output Power
Connection
PD5-CE6HDWRMBS PD5-CE6HDWRMBS
Waveform Sinewave
Main Mode Overload
> 150% minimum 200 mS, 125 to 150% for 60 seconds;
105 to 125% for 5 minutes; ≤ 105% continuous
User-congurable VAC
200/208/220/230/240 VAC
(Adjustable using operation/display conguration options)
Bypass parameters
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable-bypass
operation
When the input frequency prevents synchronous operation.
Internal Battery Charger
Charger Current, A default 2.25 A, maximum 5 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Qty×V×Rating 16 x 12V x 9.0AH
Battery Mfr./Part# 9AH; LEOCH/DJW12-9.0
Back-up time See Battery Run Times on page 120. See Battery Run Times on page 121.
Environmental Requirements
Operating Temperature,
°F (°C)
0 to 40 (32 to 104) (no derating)
Storage Temperature, °F
(°C)
-20 to +60 (-4 to +140) ( contain batteries will be from -15 to 40 °C.)
Relative Humidity 0 to 95% non-condensing
Operating Elevation Up to 3,000 m (9,842.5 ft) at 25°C (77°F) without derating
Audible Noise Front and Side <55 dBA
Agency
Safet
y*
IEC 62040-1: 2008 (First Edition) + Am 1:2013, EN 62040-1:2008+A1:2013
EMI/EMC/C-Tick EMC
IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 6); FCC Part 15 (Class A)
CISPR22 Class A (RFI)

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
