Installation28
Figure 2-2 EBCs connected to the 5/6 K UPS
ITEM DESCRIPTION
1 EBC-detection dry-contact port (See Table 2-3 on page 33, for details.)
2 EBC connector
3 EBC-detection port
4 External battery cabinet
5 External battery cabinet
