Operation and Display Panel68
Power o time
Sets the time of day to power off the UPS on the selected day. This option is only shown when sleep
mode is enabled.
• 00:00 - 23:59 (default 00:00)
IT system compatibility
When this option is enabled, the “Input phase reversed” and “Input ground lost” alarms are disabled.
• Enable
• Disable (default)
Output Parameter Options
Apply the same settings as outlet 1
Available on outlets 2 through 4, this applies the settings for Outlet1 to this outlet. This lets you apply the
settings for Outlet1 and apply identical settings to any other programmable outlet.
Turn on/o outlet
Turns on or turns off the outlet based on the current state. Provides a confirmation window with Yes/No
options to confirm turning on the outlet.
Turn on delay
Sets whether or not to turn off the outlet if the UPS is overloaded while on battery power. This can be
used to disable lower priority equipment in the event of an overload while in battery mode.
• 0 to 30 minutes (default is 0)
Turn o when UPS overload on battery
Sets whether or not to turn off the outlet if the UPS is overloaded while on battery power. This can be
used to disable lower priority equipment in the event of an overload while in battery mode.
• Yes
• No (default)
Outlet settings based on discharging time
Threshold of turning o the outlet
Length of time that the outlet is powered after the batteries begin to discharge. Select the checkbox to
enable or disable (default) the option.
• 0 to 30 minutes (default is 5)
Turn on when power returns fort
Length of time after the mains input power returns before turning on the outlet. Select the checkbox to
enable (default) or disable the option.
• 0 to 30 minutes (default is 0)
