Vertiv | Liebert® GXT5™ | Installer/User Guide 83
UPS MODEL NUMBER BATTERY PACK MODEL NUMBER QUANTITY REQUIRED
GXT5-3000IRT2UXL
GXT5-72VBATKIT
1
GXT5-3000IRT2UXLE
GXT5-5000IRT5UXLN
GXT5-192VBATKIT
GXT5-5000IRT5UXLE
GXT5-6000IRT5UXLN
GXT5-6000IRT5UXLE
GXT5-8000IRT5UXLN
GXT5-8000IRT5UXLE
GXT5-10KIRT5UXLN
GXT5-10KIRT5UXLE
GXT5-16KIRT9UXLN
GXT5-192VBATKIT 2
GXT5-16KIRT9UXLE
GXT5-20KIRT9UXLN
GXT5-20KIRT9UXLE
To replace a battery pack:
• The internal battery pack is hot-swappable. However, you must exercise caution because; during this
procedure, the load is unprotected from disturbances and power outages. Do not replace the battery
while the UPS is operating in Battery Mode. This will result in a loss of output power and will drop the
connected load.
1. For 0.75-kVA to 3-kVA models ,Press the button on the left-front of the UPS front panel, and pull the panel
open, then, loosen and remove the screw from the battery door, see Figure 5-1 on the next page.
2. Lay the battery door and screw aside for reassembly.
3. Grasp the battery handle, and pull out the battery pack, see Figure 5-1 on the next page.
4. Unpack the replacement battery pack, taking care not to damage the packaging to re-use when disposing of
the old battery.
5. Compare the new and old battery pack to make sure they are the same type and model.If so, proceed with
step 6.If they are dierent, stop and contact your Vertiv representative, or Technical Support, http://www.
Vertiv.com/ en-us/support/.
6. Line-up and slowly push-in each replacement battery pack.The battery is fully-inserted if the battery door
ts ush against the UPS.
7. Re-attach the battery door with the screw, and replace the front cover.
8. Activate the new battery pack(s) using the operating/display panel.
