Page 108 of 295
Recommendations:
Warnings:
• Please follow the important LC3 mounting guidelines.
• LC3 is for use in push or pull applications, cable outlet from smallest profile (top) or biggest profile (bottom). See top and bottom plate dimensions.
• When washing according to IPX6 parameters please notice that the large profile of the LC3 column must be placed upwards (bottom up).
• We recommend making a functional test of the application with all accessories connected before putting it into operation.
• Regular cleaning is recommended to reduce bacteria and increase the hygiene level
• Intended for indoor use only
• Not intended for use in harsh environments like e.g. pool environment, marine environment and agriculture buildings with ammonia vapors.
• Always check correct assembly after mounting and service to ensure that the cable locks are mounted.
• Ensure that the cable cannot be squeezed, pulled or subjected to any other stress or damages.
• LC3 is heavy (more than 10 kg). To avoid personal injury and product damage, DO NOT DROP!
• Take special precautions concerning 3rd party interfacing. Please contact LINAK for further information.
• Do not exceed the max. pull load specified on the label.
• Do not add dynamic load when changing between pull and push.
• Do not adjust anything during movement or while connected to mains, it can cause personal injury.
• To avoid cable interruption and actuator defects make a proper cable installation and inspect regularly for wear,
damage and jarring sound. Defective parts must be replaced.
• After service inspection, the application must be tested for correct functionality before it is put into operation,
to avoid misalignment between two columns moving in parallel.
• LINAK recommend using a safety nut in medical applications! LC3 has safety nut as standard.
• Do not loosen any screws on the LC3, this can cause collapse of the column!
• LINAK recommends making regular measurement of Class 1 protective ground conductivity in the application to avoid
a disconnected grounding cable. If there are worn out or defect parts, the complete LC3 must be replaced.
• Interconnecting cables must remain plugged in during cleaning to prevent the ingress of water.
• Always retract the LC3 column fully to obtain IPX6 protection class.
