Feedback specifications
E2 (Signal)
1 NC
2 COMMON EOS*
3 M+ (Motor/Power)
4 EOS IN
5 EOS OUT
6 M- (Motor/Power)
*EOS equal to end of stroke
E3 (Encoded)
1 GND
2 VCC
3 M+ (Motor/Power)
4 Analogue encoded (Hall-A + EOS* IN/OUT)
5 NC
6 M- (Motor/Power)
*EOS equal to end of stroke
E3 (Encoded) F3 (dual Hall encoded)
1 GND
2 VCC
3 M+ (Motor/Power)
4 Analogue encoded (Hall-A + EOS* IN/OUT)
5 Hall B
6 M- (Motor/Power)
*EOS equal to end of stroke E1 (Power switch)
E1 (Power switch)
1 NC
2 NC
3 M+ (Motor/Power)
4 NC
5 NC
6 M- (Motor/Power)
E1 (Power switch) F2 (dual Hall) See next page
1 GND
2 VCC
3 M+ (Motor/Power)
4 Hall A
5 Hall B
6 M- (Motor/Power)
Analogue encoded EOS
2.65V - 3.25V NONE
2.15V - 2.65V NONE
1.65V - 2.15V OUT
1.15V - 1.65V OUT
0.65V - 1.15V IN
0.05V - 0.65V IN
Interval Hall-A EOS
2.65V - 3.25V LOW NONE
2.15V - 2.65V HIGH NONE
1.65V - 2.15V LOW OUT
1.15V - 1.65V HIGH OUT
0.65V - 1.15V LOW IN
0.05V - 0.65V HIGH IN
