Gocator Line Profile Sensors: User Manual

Gocator Web Interface • 295

2DView 3DView

Measurement Panel

Measurements, Features, and Settingss

Measurement Illustration

Determines the X position of the selected feature type.

Determines the Y position of the selected feature type.

Determines the Z position of the selected feature type.

Measurements
