Gocator Line Profile Sensors: User Manual
Gocator Device Files • 392
Element Type Description
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Circle tool
measurement
X measurement.
Measurements\Z Circle tool
measurement
Z measurement.
Measurements\Radius Circle tool
measurement
Radius measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Circle Tool Measurement
ProfileDimension
A ProfileDimension element defines settings for a profile dimension tool and one or more of its
measurements.
