Gocator Line Profile Sensors: User Manual
Gocator Device Files • 396
Element Type Description
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
SelectType 32s
Method of selecting a groove when multiple grooves are
found:
0 – Max depth
1 – Ordinal, from left
2 – Ordinal, from right
SelectIndex 32s Index when SelectType is set to 1 or 2.
Location
(X and Z measurements only)
32s
Setting for groove location to return from:
0 – Bottom
1 – Left corner
2 – Right corner
ProfileIntersect
A ProfileIntersectelement defines settings for a profile intersect tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileIntersect above.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
RefType 32s
Reference line type:
0 – Fit
1 – X Axis
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefLine
ProfileLine
Definition of reference line. Ignored if RefType is not 0.
ProfileIntersect Child Elements
