Gocator Device Files • 414
Element Type Description
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Absolute
(Height, Length, and Width
measurements only)
Boolean Setting for selecting absolute or signed result.
0 – Signed
1 – Absolute
Tool
A Tool element of type SurfaceEdge defines settings for a surface edge tool and one or more of its
measurements.
Element Type Description
@type String Type name of the tool.
@version String Version string for custom tool.
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Parameters\UseIntensity
GdkParamBool
Use intensity data.
Parameters\RegionCount
GdkParamInt
Count of regions.
Parameters\Region
GdkParamSurfaceRegi
on3d
Edge region parameters.
Parameters\Region1
GdkParamSurfaceRegi
on3d
Second edge region parameters.
Parameters\Region2
GdkParamSurfaceRegi
on3d
Third eddge region parameters.
SurfaceEdge Child Elements
