Gocator Line Profile Sensors: User Manual
Gocator Device Files • 422
Element Type Description
LengthTolerance 64f Length tolerance (mm).
AngleTolerance 64f Angle tolerance (degrees).
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
DepthLimitEnabled Boolean Setting to enable/disable depth limit:
0 – Disable
1 – Enable
DepthLimit
64f
The depth limit relative to the surface. Data below this limit
is ignored.
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions (Advanced tab):
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
(
Advanced
tab.)
RefRegions
(Collection) Reference regions. Contains two RefRegion elements of type
SurfaceRegion2D.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction (Advanced tab):
0 – Disable
1 – Enable
TiltXAngle 64f Setting for custom tilt correction angle X.
TiltYAngle 64f Setting for custom tilt correction angle Y.
Measurements\X Opening tool
measurement
X measurement.
Measurements\Y Opening tool
measurement
Y measurement.
Measurements\Z Opening tool
measurement
Z measurement.
Measurements\Width Opening tool
measurement
Width measurement.
Measurements\Length Opening tool
measurement
Length measurement.
Measurements\Angle Opening tool
measurement
Angle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
