Logicube Forensic Falcon

OPTIONAL ADAPTERS
Logicube Forensic Falcon™ User’s Manual 137
Although PCIe cards are designed to be be hot-
swappable, this is not always the case and the Falcon
should be turned off or rebooted when the PCI Express
Card Adapter is used.
2. Connect the PCI Express Card Adapter (F-ADP-PCI-EXP) to the PCIe
port located in the back of the Falcon.
3. Connect the SSD to the M.2 to PCIe Adapter (F-ADP-M.2-PCIE).
4. Connect the M.2 to PCIe Adapter (F-ADP-M.2-PCIE) to the PCI Express
Card Adapter (F-ADP-PCI-EXP).
12.3.2 M.2 SATA based SSDs
M.2 SATA based SSDs require the M.2 to SATA Adapter (F-ADP-M.2-SATA)
which connects directly to any of the SAS/SATA cables supplied with the
