Lorex NR800 Series User Manual

Using the Main Menu16
2. Under HDD Group, assign a group to each hard drive. To set up two hard drive
groups, assign one hard drive to group 1 and the other to group 2.
3. Click OK. The system will restart to apply changes.
4. When the system restarts, you must decide which channels will record to each hard
drive group.
5. From the Main Menu, click
and then click Storage>HDD Advance>Main
Stream. For each channel, select the hard drive group you would like to record the
main stream (high quality) video and then click Apply.
6. Click the Sub Stream tab. For each channel, select the hard drive group you would
like to record the sub stream (reduced quality) video and then click Apply.
#LX400021; r. 4.0/30344/30494; en-US
68

Lorex NR800 Series Specifications

General

Brand	Lorex
Model	NR800 Series
Category	Network Hardware
Language	English
