The GS550 System
The GS550 System
10.Test for boom deflection: is the radius indicated
equal to the actual radius with the boom at 0
degrees and at 90 degrees but greater than the
actual radius with the boom at 45 degrees? If
yes then adjust the boom deflection value to
compensate:
a. Raise the boom to 45 degrees with a
known load.
b. Compare the indicated radius with the
actual radius. Change the boom
deflection value and again compare the
radius displayed with the actual radius.
Repeat until the radius displayed equals
the actual radius.
11. Test № 4: measure the actual radius and
compare to the radius indicated. Repeat with the
boom at minimum angle, at 45 degrees, and at
maximum boom angle; repeat at minimum and
maximum boom length**. If radius indication is
not accurate then refer to Radius Settings.
2.6b Radius Settings
1. Go to menu 4C) RADIUS SETTINGS.
2. Enter the user password and press Enter to go
to the first radius settings page 4C1) BOOM
LENGTH.
3. Use Back and Next to navigate between the
radius settings pages and use Up and Down to
adjust the settings.
4. Press Enter to save any changes and press
Exit three times to return to the operation
display.
** Telescopic boom cranes only
Figure: Radius settings
* Basic radius parameters
Note: with the boom at 45° and the maximum load
on the hoist, the boom deflection value should
equal the difference between the actual and the
displayed radius. With the boom at 45° and half the
maximum load on the hoist, the boom deflection
value should equal twice the difference between
the actual and the displayed radius.
IMPORTANT! Radius settings 4C14) to
4C21) are specific to the hoist line (or
sheave number) selected in Select hoist main.
!
!
Operation Display
4) Installation
4C) Radius Settings
Enter user password:
aaa
4C1) Boom length
60.0
4C2) Slew offset
0.0
4C3) Boom foot height
0.0
4C4) Boom deflection
0.0
4C5) Boom top length
0.0
4C6) Boom top offset
0.0
4C7) No load Deflection
0.0
4C8) Jib offset
0.0
4C9) Lattice extension offset
0.0
4C10) Jib mounting point
perpendicular 0.0
4C11) Jib mounting point
parallel 0.0
4C13) Select hoist main
4C14) Jib length
0.0
4C15) Luffing jib length
0.0
4C16) Lattice extension length
0.0
4C17) Manual length
0.0
4C18) Sheave head length
perpendicular 0.0
4C19) Sheave head length
parallel 0.0
4C20) Sheave radius
0.0
4C21) Deduct
0.0
*
*
*
*
4C12) Height tolerance
10.0
