The GS550 System
The GS550 System
7.4
7.4
GS550 Display Labels
GS550 Display Labels
Figure: GS550 Display labels position
CSA Class 1 Div 2 and ATEX
1- Label UB217; 2- Label UB227
3- Label UB226; 4- Label UB296 (ATEX);
4- Label UB228 (CSA specific);
5- (CSA Class I Div 2); 5- (ATEX);
7.5
7.5
Class 1 Division 1 and
Class 1 Division 1 and
Division 2 certifications
Division 2 certifications
Class 1, Division 1 certification (intrinsically safe) is
available for most
LSI
LSI sensors. Class 1, Division 2
certification (non-incendive) is available for the
GS550 display.
Certificate CSA #1332949 on master contract
215780 is available on request
Applicable requirements certified by CSA include:
•CSA Standard C22.2 No.0.4-M2004: Bonding
and grounding of electrical equipment
(protective grounding)
•CSA Standard C22.2 No.0-M1991: General
requirements Canadian electrical code part II.
•CSA Standard C22.2 No.0142-M1987: Process
control equipment
•CSA Standard C22.2 No.157-M1992:
Intrinsically safe and non-incendive equipment
for use in hazardous locations
•CSA Standard C22.2 No.213-M1987: Non-
incendive electrical equipment for use in class
I, division 2 hazardous locations
•UL Standard 508, seventeenth edition:
industrial control equipment
•UL Standard 913, sixth edition: intrinsically safe
apparatus and associated apparatus for use in
class I, II, III, division 1, hazardous (classified)
locations (LS Series)
• UL Standard 913, seventh edition: intrinsically
safe apparatus and associated apparatus for
use in class I, II, III, division 1, hazardous
(classified) locations (GS Series)
•UL Standard 1604, third edition: electrical
equipment for use in class I and II, division 2,
and class III hazardous (classified) locations.
7.6
7.6
ATEX certifications
ATEX certifications
•EN 60079-0: 2004 - Electrical apparatus for
explosive atmospheres - General requirements
•EN 60079-11: 2007 - Explosive atmospheres -
Part 11: Equipment protection by intrinsic safety “i”
•EN 60079-26 Explosive atmospheres - Part 26:
Equipment with equipment protection level
(EPL) Ga
Test Report: KEMA No. 211369200.
.
M
I
L
.
R
A
T
MENU
GS550
%
01
0 2030
40
50 60 70 80 90 1
00
11
0
5
CAUTION
EX
POSURE
T
O
PRESSURE
WAS HI NG WI LL
VOID ALL
FACT ORY
WAR RA NT IE S
L
OAD SYSTE
MS
INTE
RNA
T
IONA
L
CAUTION!
DO NOT connect NOR
disconnect unless
the area is known to
be non-hazardous
WARNING!
Substitution of components
may impair suitability
for Class 1 Division 2
CAUTION
EXPOSURE TO
PRESSURE
WAS HI NG WI LL
VOID ALL
FACT ORY
WAR RA NT IES
LOAD SYSTEMS
INTERN
ATION AL
CAUTION!
DO NOT connect NOR
disconnect unless
the area is known to
be non-hazardous
WARNING!
Substitution of components
may impair suitability
for Class 1 Division 2
LSI In. GS550 CSA
12 VDC, 1.0A
Class 1 Division 2
Groups A, B, C, D
T4A
4
1
2
3
CAUTION
EXPOSURE TO
PRESSURE
WA S H I N G W I L L
VOID ALL
FAC TO RY
WA R R A N T I E S
CAUTION!
DO NOT connect NOR
disconnect unless
the area is known to
be non-hazardous
WARNING!
Substitution of components
may impair suitability
for Class 1 Division 2
or ATEX
WARNING!
POTENTIAL
ELECTROSTATIC CHARGING
HAZARD
SEE INSTRUCTIONS
LSI In. GS550 CSA
12 VDC, 1.0A
Class 1 Division 2
Groups A, B, C, D
T4A
Load Systems International
USA: (888) 819 4355
International: +1 281 664 1330
Web: www.loadsystems.com
Email: sales@loadsystems.com
WARNING!
This device is intended as an operator
aid only and is not a substitute for
safe operating practices. Read and
understand the operator’s manual.
Test before every use.
FCC ID: QVBGS550 IC: 7076A-ICGS550
* This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
ID: 40450
Load Systems International
International: +1 281 664 1330
Web: www.loadsystems.com
Email: sales@loadsystems.com
WARNING!
This device is intended as an operator
aid only and is not a substitute for
safe operating practices. Read and
understand the operator’s manual.
Test before every use.
Model №: GS550-ATEX-CE
Built in 2008
4495 Hamel Blvd, suite 110, Québec,
QC, Canada
II 3 G ExnA II T4
ID: 50000
