The GS550 System
The GS550 System
3.5
3.5
System Menu
System Menu
There are six basic menus (level one) used to program,
consult and control the GS550 system; 1) PARTS OF LINES;
2) CRANE RIGGING; 3) DISPLAY SETTINGS; 4) INSTALLATION;
5) SYSTEM DIAGNOSTIC; 6) WORK AREA DEFINIT.
The basic menus include nested sub-menus (level
two, three and four) designed to address specific tasks
including adjusting values, choosing from lists and
following “wizards” through step by step processes.
3.5a Menu Numbers
Menus are identified by a number in the upper left
corner. The basic menus (level one) are numbered
one through six. Level two menus are lettered
alphabetically. Level three menus are numbered.
Level four menus are alphabetized.
3.5b Menu Navigation
From the operation display press Menu to see the
basic menus (level one). Press Enter to drill down
one level and enter a selected menu. Press Exit to
leave a menu and return up one level. Press Next
to move to the next page within a menu; press
Back to move to the previous page within a menu.
Use Up and Down to modify numeric values and to
move through a list of choices.
3.5c Password Protection
The submenus of menu 4) INSTALLATION are
protected by a password by default. Password
settings can be adjusted in menu 4H) PASSWORD
SETTINGS. If the user password is forgotten, it can
be changed as long as the administrator password
is known.
3.5d Menu Layout
The menus accessible to the operator without
password protection under the default factory
settings are listed below.
1) PARTS OF LINE
2) CRANE RIGGING
3) DISPLAY SETTINGS
3A) WEIGHT UNITS
3B) WIND UNITS
3C) DISPLAY LANGUAGE
3D) LIGHT INTENSITY
3E) LCD CONTRAST
3F) BACKLIGHT MODE
4) INSTALLATION
5) SYSTEM DIAGNOSTIC
5A) SYSTEM SENSORS DIAGNOSTIC
5B) RADIO NETWORK DIAGNOSTIC
5B1) RADIO NETWORK BACKGROUND NOISE
5B2) LIST LAST 32 SENSORS RECEIVED
5B3) SEARCH FOR SENSORS
5C) LOCKOUT DIAGNOSTIC
5C1) WHITE WIRE STATUS AND SELF-TEST
5C2) GREEN WIRE STATUS AND SELF-TEST
5C3) ORANGE WIRE STATUS AND SELF-TEST
5D) DISPLAY DIAGNOSTIC
5D1) TIME AND DATE
5D2) TIME CLOCK BATTERY TEST
5D3) EXTERNAL POWER SUPPLY VOLTAGE
5D4) INTERNAL TEMPERATURE
5D5) GS550 BASE STATION IDENTIFICATION NUMBER
5D6) GS550 (PORTABLE) BATTERY LEVEL
5D7) RADIO (CERTIFICATION AND FREQUENCY)
5E) DIGITAL INPUT DIAGNOSTIC
5E4) BLUE WIRE STATUS
1)
1A)
1A2)
1A2B)
Menu Level Four
Menu Level Three
Menu Level Two
Menu Level One
Figure: Menu Numbers
Note: most menus are circular; press Next on the
last page of a menu to return to the first page.
Note: most lists are circular; press Down on the
last entry of a list to return to the first entry.
Forgotten password? Call
LSI
LSI technical support
(Houston, TX) at 888 819 4355.
WARNING!
System limits are not
monitored when the display is in menu
mode. DO NOT operate the crane in menu
mode. DO NOT navigate system menus when
operating the crane.
!
!
