LSI GS550 Installer And User Manual

OPERATION
OPERATION
31
31
INSTALLATION
INSTALLATION
2.13c Rope Payout Limits
The minimum and maximum rope payout (length)
limits and the maximum rope speed limit can be
adjusted in the display in the limit menu. The
maximum rope payout limit can be programmed to
trigger lockout when exceeded, see menu 4G)
LOCKOUT SETTINGS. The minimum rope payout limit
and the maximum rope speed limit will trigger an
alarm when exceeded. The default limit for
maximum rope payout is 300 feet; the default
minimum limit is -300 feet. The default limit for
maximum rope speed is 15.0 feet per second.
2.13d Electrical connections
Voltage: 9 to 30 Volts DC, about 0.3 Amp
Red wire: positive voltage
Blue wire: negative or ground
Two types of connections are recommended;
1) Always powered up
2) Powered-up at the same source as the
GS550 display unit
Operation Display
4) Installation
4B) Sensor Calibration
Enter user password:
aaa
4B1) Automatic value
calibration wizard
4B1A) No. x ID:GXXXXX
Rope payout
Communicating with
remote sensor
Rope payout calibration
wizard. Press Next.
1/8) Confirm current
unts: (feet/metres)
2/8) HoistUp - Pay in
rope length: xx.x
3/8) Adjust actual rope
length: xx.x
4/8) HoistDown - Payout
rope length: xx.x
5/8) Adjust actual
rope length: xx.x
6/8) Calib result
Trim: xx.x
7/8) Calib result
Scale: x.xxxx
8/8) Press Enter to save
calib in sensor
Figure: Rope payout calibration
