LSIS XEC-DR32H User Manual

Chapter 8 Built-in High-speed Counter Function
(2) Interface with external devices
The following table shows list of interface with external device.
I/O Internal circuit
Terminal
No.
Signal
Operation
On/Off
guaranteed
voltage
※2
1-phase 2-phase
Input
IX0.0.0
Ch 0
Pulse input
Ch 0
A-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.1
Ch 1
Pulse input
Ch 0
B-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.2
Ch 2
Pulse input
Ch 2
A-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.3
Ch 3
Pulse input
Ch 2
B-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.4
Ch 4
Pulse input
Ch 4
A-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.5
Ch 5
Pulse input
Ch 4
B-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.6
Ch 6
Pulse input
Ch 6
A-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.7
Ch 7
Pulse input
Ch 6
B-phase input
On 20.4~28.8V
Off 6V or less
IX0.0.8
Ch 0
Preset input
Ch 0
Preset input
On 20.4~28.8V
Off 6V or less
IX0.0.9
Ch 1
Preset input
-
On 20.4~28.8V
Off 6V or less
IX0.0.10
Ch 2
Preset input
Ch 2
Preset input
On 20.4~28.8V
Off 6V or less
IX0.0.11
Ch 3
Preset input
-
On 20.4~28.8V
Off 6V or less
IX0.0.12
Ch 4
Preset input
Ch 4
Preset input
On 20.4~28.8V
Off 6V or less
IX0.0.13
Ch 5
Preset input
-
On 20.4~28.8V
Off 6V or less
IX0.0.14
Ch 6
Preset input
Ch 6
Preset input
On 20.4~28.8V
Off 6V or less
IX0.0.15
Ch 7
Preset input
-
On 20.4~28.8V
Off 6V or less
COM0
COM (input common)
※2 : on guaranteed voltage is 9V, off guaranteed voltage is 5V for XEC-DR32(64)H/D1 unit.
2.7 kΩ
2.7 kΩ
2.7 k
Ω
2.7 kΩ
2.7 kΩ
2.7 kΩ
2.7 kΩ
2.7 kΩ
5.6 kΩ
5.6 kΩ
5.6 k
Ω
5.6 kΩ
5.6 kΩ
5.6 kΩ
5.6 kΩ
5.6 k
Ω
8-3
