Chapter 8 Built-in High-speed Counter Function
8.4 Examples: Using High-speed Counter
It describes examples of using high-speed counter.
(1) Setting high-speed counter parameter
How to set types of parameters to operate a high-speed counter is described as follows.
(a) Set 『Internal Parameters』 in the basic project window.
(b) Selecting high-speed counter opens a window to set high-speed counter parameters as follows.
For details regarding each parameter setting, refer to 8.1~8.3.
(Every parameter settings are saved in the special K device area.)
8-28
To Next Page
