Chapter 5 Program Configuration and Operation Method
5.4 Memory
There are two types of memory in CPU module that the user can use. One is Program Memory that saves the
user program written by the user to build the system, and the other is Data Memory that provides the device area
to save the data during operation.
5.4.1 Program memory
Contents and size of program memory are as follows.
Item
Size
Program memory entire area
1.76 MB
System area:
 System program area
 Backup area
512 KB
Parameter area:
 Basic parameter area
 I/O parameter area
 High speed link parameter area
 P2P parameter area
 Interrupt setting information area
 Reserved area
48 KB
Execution program area:
 Scan program area
 Task program area
200 KB
Program reserved area
 Scan program backup area
 Task program area
 Upload area
 User defined function/function block area
 Variable initialization information area
 Reserved variable assignment information area
 Reserved area
1 MB
5- 25
