Chapter 8 Built-in High-speed Counter Function
8.3.2 Error code
It describes errors of the built-in high-speed counter.
▪ Error occurred is saved in the following area.
Category
Device area per channel
Remark
Ch0 Ch1 Ch2 Ch3 Ch4 Ch5 Ch6 Ch7
Error code
%KW266 %KW276 %KW286 %KW296 %KW2186 %KW2196 %KW2206 %KW2216
Word
▪ Error codes and descriptions
Error code
(Decimal)
Description
20 Counter type is set out of range
21 Pulse input type is set out of range
22
Requesting #1(3,)channel Run during the operation of #0(2) channel 2 phase(
* During #0(2) channel 2 phase inputting, using #1(3)channel is not possible.
23 Compared output type setting is set out of range.
25 Internal preset value is set out of counter range
26 External present value is set out of counter range
27
Ring counter setting is set out of range
* Note ring counter setting should be 2 and more.
28 Compared output min. value is set out of permissible max. input range
29 Compared output max. value is set out of permissible max. input range
30 Error of Compared output min. value>Compared output max. value
31 Compared output is set out of the default output value
34 Set value of Unit time is out of the range
35 Pulse value per 1 revolution is set out of range
36 Compared output min. value is set out of permissible max. input range (Compared output1)
37 Compared output max. value is set out of permissible max. input range (Compared output1)
38 Error of Compared output min. value>Compared output max. value (Compared output1)
39 Compared output is set out of the default output value (Compared output1)
Remark
▪ If two and more errors occur, the module saves the latter error code and removes
the former one.
8-27
