LSIS XEC-DR32H User Manual

Chapter 5 Program Configuration and Operation Method
5.4.4 Data Memory Map
User program area
Parameter area
User program area
(200 KB)
Data area
Automatic variable
(32 KB)
Z127
Z000
Input variable
(2 KB)
“
I
”
%IX0.0.0
%IX15.15.63
Output variable
(2 KB)
“
Q
”
%QX0.0.0
%QX15.15.63
Direct variable M area
(16 KB)
“M”
%MW8188
%MW0
Direct variable R area
(20 KB)
“R”
%RW10236
%RW0
Direct variable W area
(20 KB)
“W”
%WW10236
%WW0
Direct variable F area
(2 KB)
“F”
%FW1020
%FW0
Direct variable K area
(8 KB)
“K”
%KW4092
%KW0
Direct variable L area
(4 KB)
“L”
%LW2044
%LW0
Direct variable N area
(10 KB)
“N”
%NW5116
%NW0
Direct variable U area
(1 KB)
“U”
%UW0.15.31
%UW0.0.0
5- 28
