Chapter 4 CPU Specifications
4.4 Calculation Example of Consumption Current/Voltage
Calculate the consumption current and configure the system not to exceed the output current capacity of
main unit.
(1) XGB PLC configuration example 1
Consumption of current/voltage is calculated as follows.
Type Model Unit No.
Internal 5V
consumption
current
(Unit :
㎃
)
Remark
Main unit XEC-DN32H 1 260
In case contact points are On.
(Maximum consumption current)
Expansion
module
XBE-DC32A 2 50
XBE-TN32A 2 80
XBF-AD04A 1 120
All channel is used.
(Maximum consumption current)
XBF-DC04A 1 110
XBL-C21A 1 120
Consumption
current
870 ㎃
-
Consumption
voltage
4.35 W
0.87A ⅹ 5V = 4.35W
In case system is configured as above, since 5V consumption current is total 870 mA and 5V output of XGB
32 points main unit is maximum 2A, normal system configuration is available.
(2) XGB PLC configuration example 2
Type Model Unit No.
Internal 5V
consumption
current
(Unit :
㎃
)
Remark
Main unit XEC-DR32H 1 660
In case all contact points are On.
(Maximum consumption current)
Expansion
module
XBE-DR16A 5 250
XBE-TN32A 2 80
XBF-AD04A 1 120
All channel is used.
(Maximum consumption current)
XBL-C21A 1 120
Consumption
current
2,310mA -
Consumption
voltage
11.55W 2.31 * 5V = 11.55W
If system is configured as above, total 5V current consumption is exceeded 2,310mA and it exceeds the 5V
output of XGB 32 points main unit. Normal system configuration is not available. Although we assume the
above example that all contact points are on, please use 64 points main unit which 5V output capacity is
higher than standard type main unit.
4- 6
