Chapter 2 System Configuration
(c) 1:1 RS-232C Communication with remote device via modem by Cnet I/F modules
(d) 1:1 communication of an external device (monitoring unit) with main unit using a built-in RS-
232C/485 port.
Modem
Modem
XBL-C21A
XEC-DR32H
XBL-C21A
XEC-DR32H
Modem
Modem
XBL-C21A
XEC-DR32H
Built-in RS-232C/485 connection
XP30-TTA
XEC-DR32H
