Lucent 5ESS DRM User Manual

Table 1-1 — DRM Equipment Comcode Numbers
Workstation FRU Description Comcode Number Replacement Procedure
Netra t 1120 440Mhz DRM Netra t 1120, 18G drives (2 SAI, 1 HSI, 1 QFE
PCI card)
(only this Netra t 1120 workstation configuration is stocked in
SES. It is the max configuration)
848749404 Procedure 4.6
Netra t 1120 DDS3 DAT Drive 408149086 Procedure 4.11
Netra t 1120 18.2GB Disk Drive 408018513 Procedure 4.5.1
Netra t 1120 CD/DVD-ROM 408537629 Procedure 4.11
The items below this point are not stocked in SES.
Netra t 1120
a
300Mhz DRM Netra t 1120, 18G drives (1 SAI, 1 QFE PCI
card)
848590121 Procedure 4.6
Netra t 1120
a
300Mhz DRM Netra t 1120, 18G drives (2 SAI, 1 HSI, 1 QFE
PCI card)
848611802 Procedure 4.6
Netra t 1120
a
300Mhz DRM Netra t 1120, 18G drives (2 SAI, 1 QFE PCI
card)
848611828 Procedure 4.6
Netra t 1120
a
300Mhz DRM Netra t 1120, 18G drives (1 SAI, 1 HSI, 1 QFE
PCI card)
848611836 Procedure 4.6
Netra t 1120
a
440Mhz DRM Netra t 1120, 18G drives (1 SAI, 1 QFE PCI
card)
848770566 Procedure 4.6
Netra t 1120
a
440Mhz DRM Netra t 1120, 18G drives (2 SAI, 1 QFE PCI
card)
848770541 Procedure 4.6
Netra t 1120
a
440Mhz DRM Netra t 1120, 18G drives (1 SAI, 1 HSI, 1 QFE
PCI card)
848770558 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 36G drives (1 SAI, 1 QFE PCI card) 848883617 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 36G drives (2 SAI, 1 QFE PCI card) 848883625 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 36G drives (2 SAI, 1 HSI, 1 QFE PCI
card)
848883633 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 36G drives (1 SAI, 1 HSI, 1 QFE PCI
card)
848883641 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 73G drives (1 SAI, 1 QFE PCI card) 848940847 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 73G drives (2 SAI, 1 QFE PCI card) 848940854 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 73G drives (2 SAI, 1 HSI, 1 QFE PCI
card)
848940862 Procedure 4.6
Netra 20
b
900Mhz DRM Netra 20, 73G drives (1 SAI, 1 HSI, 1 QFE PCI
card)
848940870 Procedure 4.6
Netra 20
b
DDS4 DAT Drive 408715829 Procedure 4.12
Netra 20
b
36GB Disk Drive 408715811 Procedure 4.5.2
or Procedure 4.5.3
Netra 20
b
73GB Disk Drive 408784536 Procedure 4.5.2
or Procedure 4.5.3
Netra 20
b
DVD-ROM 408537629 Procedure 4.12
Netra 240
b
1.5 Ghz VCDX Netra 240,146G drives (2 SAI, 1 HSI PCI card) 849005970 Procedure 4.13
Netra 240
b
External DAT72 Drive 408923878 Procedure 4.14
Netra 240
b
146G SCSI Disk Drive 408923662 Procedure 4.5.4 and 4.5.5
Netra 240
b
DVD-RW Drive 408923712 Procedure 4.17
Netra 240
b
Power Supply 408924496 Procedure 4.18
Note(s):
a. Comcode 848749404 should be requested as a compatible replacement from SES. Please ensure that the box the
defective Netra t 1120 is returned in has a clearly visible label that specifies Comcode 848749404.
b. SES-5 does not support this item.
INTRODUCTION 235-200-150
January 2007
Page 1-6 Issue 3.00N
