Lucent 5ESS DRM - Broadcom Gigabit Ethernet (BGE) Interface ( Netra 240)

Table 2-7 — QFE Port Assignment
QFE Port Ethernet Networks
0 ASM
1 Not assigned
2 Not assigned
3 Not assigned
2.9.4
Broadcom Gigabit Ethernet (BGE) Interface ( Netra 240)
The onboard BGE ports are used to interface up to four Ethernet networks. Figure
2-24 illustrates the connections to the AW. Table 2-8 lists Ethernet networks that are
interfaced using the BGE ports.
Figure 2-24 — BroadcomGigabit Ethernet — Netra 240 Interface Connections
