3.7 Configure the Router to Support Serial Asynchronous Interface (SAI) at the
DRM Site
OVERVIEW
The following procedure sets up the configuration of the DynaStar 500
1
to allow a
vt100 terminal to connect to a port at a DynaStar unit that is remote from the DRM
to provide the user with the same access to RC/V and STLWS as any terminal set up
for OAM&P.
Remote output channels can be provisioned for:
• traffic
• office record
• balance
Purpose
The following procedure configures the DRM site router to support Serial
Asynchronous Interface (SAI).
When to Use
The following procedure should be used to provide access to the DRM SAI ports by:
• Collecting the data from the dedicated serial ports on the DynaStar 500 through
Telnet, or
• Collecting the data from the SAI ports at a dedicated VT100 terminal.
Before You Begin
Required Conditions
The following conditions should exist before the procedure is performed:
• The router is connected to the network.
• A terminal (laptop computer or VT100 terminal) is connected to the network.
• Use Procedure 3.1, Local Log on to the Networking Router, to get to the main
menu of the unit.
Select the terminal application and SAI port. Follow the specific terminal’s growth
procedures:
• 8.3, Perform STLWS Growth
• 8.4, Perform RC/V Terminal Growth
• 8.11, Perform TDMS/EADAS Data Link Growth
Required Materials
A cable is needed to connect the SAI port on the Administrative Workstation to the
port of the networking router at the DRM site:
• 5 ft. cable (COM CODE: 408355543), or
1. Trademark of DYMEC, Inc.
235-200-150
January 2003
NETWORK PROCEDURES
Procedure 3.7
Issue 3.00 Page 3.7-1
