3.1 Local Log on to the Networking Router
Purpose
Use this procedure to locally access the networking router.
When to Use
This procedure is performed prior to:
• configuring the router at the DRM site
• backing up the router configuration files
• restoring the router.
Before You Begin
A supervisor console (VT100 terminal or laptop) must be connected to the console (port
6ontheDynaStar 500
1
) using the appropriate cables.
Required Tools
The following equipment is required to perform the procedure:
• PC with VT100 emulator software or a VT100 terminal is connected to port 6 of
the networking router.
If the connection does not exist:
— At the back of the networking router, connect the cable with an RJ-69
interface to Port 6.
— At the back of the PC or VT100 terminal, connect the other end of the cable
to the serial port.
Note: If a DB-9 cable is used, connect a DB-25 adapter to the DB-9 cable
before connecting the cable to the back of the networking router.
• At the PC or VT100 terminal, verify that the communication parameters are set
to 9600 bps and even parity (7 bits, even, 1 stop).
• A cable with an RJ-69 interface
• An RJ-69 to DB-25 connector
• A DB-9 to DB-25 connector (Customer provided)
Required Information
When the VT100 PC/terminal starts up, the DynaStar 500 Supervisor page appears.
If the * prompt appears on the Supervisor Console, type and enter 9999 at the *
prompt to display the DynaStar 500 Supervisor page.
PROCEDURE
1. At the Enter Password: prompt, type and enter secret (or the password set for
your office).
Response: The Supervisor Console Types information appears.
1. Trademark of DYMEC, Inc.
235-200-150
October 2004
NETWORK PROCEDURES
Procedure 3.1
Issue 3.00L Page 3.1-1
