Table 3.15-5 — Verify Connectivity Between ASM and Remote Router
Host Router Replaced Remote Router Command Response
Host Router A Remote Router 1 ping 10.10.8.6 10.10.8.6 is alive
Host Router A Remote Router 2 ping 10.10.8.10 10.10.8.10 is alive
Host Router A Remote Router 3 ping 10.10.8.14 10.10.8.14 is alive
Host Router A Remote Router 4 ping 10.10.8.18 10.10.8.18 is alive
Host Router A Remote Router 5 ping 10.10.8.22 10.10.8.22 is alive
Host Router B Remote Router 6 ping 10.10.16.6 10.10.16.6 is alive
Host Router B Remote Router 7 ping 10.10.16.10 10.10.16.10 is alive
Host Router B Remote Router 8 ping 10.10.16.14 10.10.16.14 is alive
Host Router B Remote Router 9 ping 10.10.16.18 10.10.16.18 is alive
Host Router B Remote Router 10 ping 10.10.16.22 10.10.16.22 is alive
Host Router C Remote Router 11 ping 10.10.24.6 10.10.24.6 is alive
Host Router C Remote Router 12 ping 10.10.24.10 10.10.24.10 is alive
Host Router C Remote Router 13 ping 10.10.24.14 10.10.24.14 is alive
Host Router C Remote Router 14 ping 10.10.24.18 10.10.24.18 is alive
Host Router C Remote Router 15 ping 10.10.24.22 10.10.24.22 is alive
d. Verify the connectivity between the ASM and all DRMs that are configured
under the replacement Host Router:
The format of the ping command is:
ping <IP address of DRM>
The value for the IP address of the DRM depends on the DRMs that are
configured under the replacement Host Router. Type and enter all of the
following commands that correspond to the DRMs that are configured under
the replacement Host Router (see table 3.15-6).
235-200-150
October 2004
NETWORK PROCEDURES
Procedure 3.15
Issue 3.00L Page 3.15-9
