2.8, “Optional Local Terminal Interfaces” for more information on terminal and data
link devices.
• SCSI port (Netra 240) – used to connect the DAT drive unit to the workstation.
• Ethernet Quad Fast Ethernet (QFE) port 0 (Netra t 1120, Netra 20) – interface
between the AW and the ASM to establish a network connection between the
DRM and the 5ESS Switch. The Ethernet cable uses an RJ-45 to interface the
hub or router. This cable is used for the network connection to the ASM.
• Ethernet Broadcom
3
Gigabit Ethernet
4
(BGE) port 2 (Netra 240) – interface
between the AW and the ASM to establish a network connection between the
DRM and the 5ESS Switch. The Ethernet cable uses an RJ-45 to interface the
hub or router. This cable is used for the network connection to the ASM.
• Ethernet port – interface between the AW and the SM. The Ethernet cable uses a
tee-connector to interface both sides of the Module Controller/Time Slot
Interchanger (MCTSI) .
• PCI slots (Netra t 1120, Netra 20, and Netra 240) – support the High Speed
Interface (HSI) card for data link connections and Serial Asynchronous Interface
(SAI) cards for terminal and printer connections.
• Serial port DB-9 (Netra 240) – used to connect the Solaris
5
console terminal to
the AW.
• Serial ports A and B (Netra t 1120 and Netra 20) – serial port A is used to
connect the Solaris console terminal to the AW. Serial port B is used to connect
the MCC terminal to the AW.
• Parallel port (Netra t 1120 and Netra 20) – used to connect a ROP to the AW.
3. Registered trademark of Xerox Corporation.
4. Registered trademark of Xerox Corporation.
5. Registered trademark of Sun Microsystems, Inc.
5ESS
®
SWITCH DISTINCTIVE REMOTE MODULE 235-200-150
Feburary 2007
Page 2-6 Issue 3.00O
