LulzBot TAZ User Manual

Your First 3D Print
5.1 Set Temperature
Make sure to first read the instructions for using the Printrun software.
Connect to the printer as described in the Printrun software section (page
30). Set the hot end and print surface for ABS or PLA plastic and turn both
on. The temperature settings for ABS should be set at 230
◦
C for the hot
end and 85
◦
C for print surface; for PLA they should be set at 180
◦
C-185
◦
C
for the hot end and 60
◦
C for print surface. If you have not already, make
sure the axes end stops are aligned to be triggered when each axis homes.
Click the Motors Off button.
5.2 Inserting Filament Into the Extruder
Once the hot end is heated to the correct temperature you will now need to
load the plastic filament into the extruder. Raise both the idler clip and the
2 screws adding tension to release the hinged idler. It can be loosened if
necessary. (Fig. 5.1). Gently pull both the idler screws and the plastic clip
Figure 5.1: Extruder idler release
upwards to release the idler. The idler can be rotated downwards allowing
92

LulzBot TAZ Specifications

General

Nozzle Diameter	0.5 mm (standard), interchangeable
Print Speed	Up to 200 mm/s
Max Hotend Temperature	300°C
Max Heated Bed Temperature	120°C
Connectivity	USB
Supported Materials	PLA, ABS, HIPS, PVA, PETG, Nylon, TPE, TPU, PC, wood-filled
Print Surface	PEI-coated borosilicate glass bed
Bed Leveling	Automatic
Operating System Compatibility	Windows, macOS, Linux
Power Requirements	100 - 240 VAC
Print Technology	Fused Deposition Fabrication (FDM)
