Figure 2.81: Console Control Plate
14. Inside the windrower cab, remove cover (A) from the
console by removing five screws (B).
$
Figure 2.82: Console Control Plate
15. Cut a hole in the decal and install rotary switch (A) as
shown. There is a premade hole in the mounting plate.
$
Figure 2.83: Console Control Plate
16. Remove the knockout in cover (A) for the rocker switch. File
down the burrs on the knockout.
