11.2 I/O control AT command
11.2.1 Read digital input status
AT+IOBR
Read the value of one or all input pins on I/O ports.
Syntax: AT+IOBR[=<pin>]
Response:
+IOBR: <val><val>
+IOBR: <pin>,<val>
Defined Values:
<pin> id of the digital input read. Valid value is from 1 to 2. If <pin> entry is omitted all input pins will be read.
<val> current value of the digital input:
1 input is high.
0 input reading is low
Example:
Command
Response
AT+IOBR
+IOBR: 00
OK
Note: read all digital input status.
AT+IOBR=1
+IOBR: 1,0
OK
Note: read the value of input pin #1.
AT+IOBR=?
+IOBR[: (1-2)]
OK
Note:
When command is entered without <pin> entry, the response shows the value of input pins in a series of 0 or
1, from left (pin #1) to right (pin#2).
11.2.2 Set digital output status
AT+IOBW
Set (write) the value of one or all digital outputs pins on I/O ports.
Syntax:
AT+IOBW=<pin>,<val>
AT+IOBW=<val><val>
Response:
+IOBOR: <pin>,<val>
+IOBOR: <val>,<val>
60 Confidential, the whole document is the sole property of Maestro Wireless Solutions ltd.
