For Inputs %IP and Outputs %OP refer to the table below:
Input 1 Input 2 %IP value Output 1 Output 2 %OP value
Low Low 3 Drain Drain 3
High Low 2 Open Drain 2
Low High 1 Drain Open 1
High High 0 Open Open 0
Invalid Service name or Id will be ignored.
Note:
1. To use Email Sending Service make sure all parameters has been setup properly first:
(a) APN (+IPGPRS)
(b) SMTP server (+IPSMTP)
(c) Sender and recipient address (+EMADDR)
(d) Subject (+EMSUBJ)
(e) Body (+EMBODY)
(f) It is strongly suggested you have tested the email sending function by using AT+EMSEND command to
send test emails first before using EM Command Sting.
2. If Operation argument of TO, CC, BC, SU and BD is set to 0 (default), the associated Email set will not contain
that element.
3. A minimum email contains one recipient (either TO, CC or BC) and one character of additional email content.
4. Unlike AT+EMSEND command, sending email use EM service will automatically making cellular connection
(+IPCONNECT=1,1).
5. In case email sending is unsuccessful due to any reason, the same email will be resent for max 2 more times.
If all retries are fail that Email will be aborted.
6. When using EM service maximum 10 emails can be put on sending queue, further Email sending requests will
be aborted. Buffered email queue is volatile and will be lost If modem Is power off or reset. Also when there is
EM service in queue AT+EMSEND command will not be allowed.
21.8 Device Power Control Service
By using Device Power Control Service user can control on/off state of certain component of the modem, in order to
save power consumption. A single Service id field can be set to control four parts of the modem.
1st field
Service
type
2nd field
Service
id
3rd field
Operation
type
4th field
Operation argument
Explanation
PW (0 to 15) 0 0
Service Id to decide components’ on/off
state
Example: Enable low clock mode and disable LED’s.
PW␣3␣0␣0
Example: Enable low clock mode; disable LED’s, disable Serial port and unregistered from network.
PW␣15␣0␣0
100 Confidential, the whole document is the sole property of Maestro Wireless Solutions ltd.
