IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-40
C08-14 Brake Hold Speed The frequency the drive outputs to
push against the brake for brake
proving at start as well as the
frequency the drive continues to
output until Brake Set Delay Timer
expires or the Brake Answerback
MFDI is removed.
0.0–25.5% 0.0 VG+
C08-15 Load Float Ext T Load Float extension time enabled
by MFDI=5D.
0–65535 sec 10 VG+
C08-16 Init FWD Brk Trq Initial Brake Release Torque. The
percentage of forward/up motor
torque that must be reached within
C08-02 time in order for the brake
to release at the start of the run
command. (BE2 detection)
10–300% 100 VG+
C08-18 BE6 Up Speed Lim Maximum up speed limit after BE6
or BE8 alarm is detected.
0.00–150.00 Hz 6.00 G+/VG+
C08-19 Brk Slip Reset Determines if BE6 alarm is
automatically reset. If enabled,
drive will always perform BE6 test
after Load Float time to determine
if brake is operational and the fault
can be cleared. If disabled the
drive will remain in BE6 alarm
state until drive power is cycled.
0, 1 0 VG+
0 Disabled
1 Enabled
C08-20 BE6 Check Torque Torque output during a BE6 check. 0.5–20.0% 1.0 VG+
C08-21 Add Mag I Time Sets the amount of additional time
to delay during NLB start to allow
the motor to develop the additional
magnetizing current.
0.0–3.0 sec 0.0 VG+
C08-22 Brk Slip Detect Enables continuous monitoring of
the brake for NLB Hoists.
(BE8 Detection)
0, 1 0 VG+
0 Disabled
1 Enabled
C08-23 Brk Slip Det Spd Adjusts the sensitivity of Brake Slip
Detection. BE8
0–10 Hz 1.0 VG+
C08-24 Brake Test Torq Motor runs in Forward direction at
C08-25 speed when MFDI 61 is
active. Brake output Multi-function
output is not energized, PGO and
DEV detection are disabled.
Monitor Brake Test Torque at U01-
86.
0–6553.5 Flb
(see ** below)
VG+
C08-25 Brake Test Speed Speed the drive will push against
brake during testing.
0–10 Hz 6 VG+
C08-33 Dual Brake Test Enabling this will alternate the
brake outputs after every cycle.
When enabled, MFDOs must be
programmed to 00 and 0A or
OPE28 will be displayed
0, 1 0 VG+
0 Disabled
1 Enabled
C08-34 DIR Flt Trq Lvl Regen torque level required to trip
the DIR fault. This is used to
detect an NLB hoist which is set
up backwards (FWD is down). A
setting of 0 disables this feature.
0–100% 20 VG+
Parameter Display Function Range Default Model
* Initial value is determined by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
**
