IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-13
Accel/Decel Time Switching Frequency
Accel/Decel times can be changed automatically without using multi-function inputs. When multi-
function digital inputs are set for Accel/Decel selection, this command has priority over automatic
change of Accel/Decel.
Table 5-11: Accel/Decel Time Switching Frequency Parameter Settings
Jump Frequencies
This function allows the “jumping” of critical frequencies so that the motor can operate without
resonant vibrations caused by some machine systems. This function is also used for deadband
control. Setting the value to 0.0 Hz disables this function.
Table 5-12: Jump Frequencies Parameter Settings
Parameter Display Function Range Default
B05-05 Acc Time N Chg Sets Acceleration time at Acc/Dec
Switch Frequency (B05-10)
0.0–25.5 sec 2.0
B05-06 Dec Time N Chg Sets Deceleration time at Acc/Dec
Switch Frequency (B05-10)
0.0–25.5 sec 2.0
B05-08 Fast Stop Time Sets deceleration time for
complete stop at external fault.
See “External Fault Response
Selection” on page 5-96.
0.0–25.5 sec 0.5
B05-10 Acc/Dec SW Freq Determines acceleration/
deceleration time settings
0.0–E01-04 0.0
B05-11 SW Freq. Compare Determines when Acceleration
Time and Deceleration Time at
Speed Switch Hz is enabled;
0, 1 1
0 Lower SW Freq 0: B05-05/B05-06 enabled, U01-02 < B05-10
1 Upper SW Freq 1: B05-05/B05-06 enabled, U01-02 > B05-10
B05-12 Accel Time 3 Acceleration time 3 enabled when
H01-xx = 1B.
0.0–25.5 sec* 3.0
B05-13 Decel Time 3 Deceleration time 3 enabled when
H01-xx = 1B.
0.0–25.5 sec* 3.0
B05-14 Accel Time 4 Acceleration time 4 enabled when
H01-xx = 1C.
0.0–25.5 sec* 3.0
B05-15 Decel Time 4 Deceleration time 4 enabled when
H01-xx = 1C.
0.0–25.5 sec* 3.0
B05-16 Acc/Dec Ext Rang Enables extended range of Acc/
Dec Params: B05-01–B05-04,
B05-12–B05-15, C03-02, C03-03,
C03-05 and C03-06
0, 1 0
0 Disabled Range = 0.0–25.5
1 Enabled Range = 0.0–6000.0
* Range is extended to 0.0–6000.00 when B05-16 = 1.
Parameter Display Function Range Default
B08-01 Jump Freq 1 First of three jump frequencies. 0.0–150.0 Hz 0.0
B08-02 Jump Freq 2 Second of three jump frequencies. 0.0–150.0 Hz 0.0
B08-03 Jump Freq 3 Third of three jump frequencies. 0.0–150.0 Hz 0.0
B08-04 Jump Bandwidth Jump frequency reference
bandwidth.
0.0–20.0 Hz 1.0
