IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-121
Operator Parameters
• O1 Monitor Selection
• O2 Keypad Key Selection
• O3 Clear History
• O4 Copy Function
Monitor Selection
The top level in the operation mode allows the viewing of four monitor variables. They are Fref, Fout,
Iout, and User-Selected monitor. This user-selected monitor can be selected from the following
table. See the Monitor Parameters table on page 5-131 for available monitors by control method.
Table 5-107: Monitor Selection Parameter Settings
Parameter Display Function Range Default
O01-01 User Monitor Sel Selects the content of the last
monitor that is shown when
scrolling through Drive Mode
display. Enter the last three digits
of the monitor parameter number
to be displayed: U0X-xx.
Default: 106 (Monitor: Output
Voltage Reference U01-06)
104–813 106
104 Control Method
105 Motor Speed
106 Output Voltage
107 DC Bus Voltage
108 Output HP
109 Torque Reference
110 Input Term Sts
111 Output Term Sts
112 Int Ctl Sts 1
114 CPU 1 SW Number
115 Term A1 Level
116 Term A2 Level
117 Term A3 Level
120 SFS Output
121 AI Opt Ch1 Level
122 AI Opt Ch2 Level
123 AI Opt Ch3 Level
125 DI Opt Status
128 CPU 2 SW Number
134 OPE Error Code
139 Transmit Error
144 ASR Out w/o Fil
150 Hook Height
151 Motor Revolution
152 MaintenanceTimer
153 Index Count
154 Term RP Inp Freq
