Analog Output (AO-A3) Option Set-up
Selects the analog output monitors for channel 1 and 2 if the AO-A3 optional card is connected.
Table 5-65: Analog Output Option Set-Up Parameter Settings
Table 5-66: Parameter Settings for F04-01 and F04-03
Parameter Display Function Range Default
F04-01 AO Ch1 Select Analog output option Channel 1
selection
1–630 102
F04-02 AO Ch1 Gain Analog output Channel 1 multiplier -999.9–999.9% 100
F04-03 AO Ch2 Select Analog output option Channel 2
selection (Same as F04-01)
1–630 103
F04-04 AO Ch2 Gain Analog output Channel 2 multiplier -999.9–999.9% 50
F04-05 AO Ch1 Bias Channel 1 bias -999.9–999.9% 0.0
F04-06 AO Ch2 Bias Channel 2 bias -999.9–999.9% 0.0
F04-07 AO Opt Level Ch1 Channel 1 output signal 0, 1 0
0 0 to 10 V
1
-
10 to 10 V
F04-08 AO Opt Level Ch2 Channel 2 output signal 0, 1 0
0 0 to 10 V
1
-
10 to 10 V
Display Display
0 Not Used 165 PG Output Freq
101 Frequency Ref 184 NLB State*
102 Output Freq 185 NLB Rel Trq*
103 Output Current 408 Heatsink Temp
105 Motor Speed* 416 Motor OL1 Level
106 Output Voltage 417 Drive OL2 Level
107 DC Bus Voltage 601 Mot SEC Current
108 Output HP 602 Mot EXC Current*
109 Torque Reference* 603 ASR Input*
115 Term A1 Level 604 ASR Output*
116 Term A2 Level 605 Voltage Ref (Vq)*
117 Term A3 Level 606 Voltage Ref (Vd)*
120 SFS Output 607 ACR(q) Output*
121 AI Opt Ch1 Level 608 ACR(d) Output*
122 AI Opt Ch2 Level 611 Iq Reference*
123 AI Opt Ch3 Level 612 Id Reference*
129 Load Weight 618 PG1 CounterValue
130 SS Delta Speed 619 PG2 CounterValue
150 Hook Height* 622 Zero Servo Pulse*
154 Input Pulse Mon 626 FF Cont Output*
163 PG CH1 Freq 627 FF Estimate SPD*
164 PG CH2 Freq --
* Not available in the V/f control method (A01-02 = 0)
